Toyota Avalon (XX50) 2019-2022 Service & Repair Manual: Disassembly

DISASSEMBLY

CAUTION / NOTICE / HINT

NOTICE:

Do not damage the millimeter wave radar sensor assembly.
Do not disassemble the millimeter wave radar sensor bracket sub-assembly except when replacing it.

PROCEDURE

1. REMOVE MILLIMETER WAVE RADAR SENSOR BRACKET SUB-ASSEMBLY

(a) Remove the 2 screws and millimeter wave radar sensor bracket sub-assembly.
